Tilt
3D tilt effect that responds to mouse movement, enhancing UI elements with a dynamic depth effect, customizable rotation factors and spring options.
Examples
Basic Tilt Card
Ghost in the Shell
Kôkaku kidôtai
Tilt with Spotlight
Example of the Spotlight component used with the Tilt component.
2001: A Space Odyssey
Stanley Kubrick
Code
'use client';
import React, { useRef } from 'react';
import {
motion,
useMotionTemplate,
useMotionValue,
useSpring,
useTransform,
MotionStyle,
SpringOptions,
} from 'motion/react';
type TiltProps = {
children: React.ReactNode;
className?: string;
style?: MotionStyle;
rotationFactor?: number;
isRevese?: boolean;
springOptions?: SpringOptions;
};
export function Tilt({
children,
className,
style,
rotationFactor = 15,
isRevese = false,
springOptions,
}: TiltProps) {
const ref = useRef<HTMLDivElement>(null);
const x = useMotionValue(0);
const y = useMotionValue(0);
const xSpring = useSpring(x, springOptions);
const ySpring = useSpring(y, springOptions);
const rotateX = useTransform(
ySpring,
[-0.5, 0.5],
isRevese
? [rotationFactor, -rotationFactor]
: [-rotationFactor, rotationFactor]
);
const rotateY = useTransform(
xSpring,
[-0.5, 0.5],
isRevese
? [-rotationFactor, rotationFactor]
: [rotationFactor, -rotationFactor]
);
const transform = useMotionTemplate`perspective(1000px) rotateX(${rotateX}deg) rotateY(${rotateY}deg)`;
const handleMouseMove = (e: React.MouseEvent<HTMLDivElement>) => {
if (!ref.current) return;
const rect = ref.current.getBoundingClientRect();
const width = rect.width;
const height = rect.height;
const mouseX = e.clientX - rect.left;
const mouseY = e.clientY - rect.top;
const xPos = mouseX / width - 0.5;
const yPos = mouseY / height - 0.5;
x.set(xPos);
y.set(yPos);
};
const handleMouseLeave = () => {
x.set(0);
y.set(0);
};
return (
<motion.div
ref={ref}
className={className}
style={{
transformStyle: 'preserve-3d',
...style,
transform,
}}
onMouseMove={handleMouseMove}
onMouseLeave={handleMouseLeave}
>
{children}
</motion.div>
);
}
Component API
Border Trail
Prop | Type | Default | Description |
---|---|---|---|
className | string | Additional CSS classes for styling the tilt. | |
style | MotionStyle | Additional CSS classes for styling the tilt. | |
rotationFactor | number | 15 | Controls the maximum rotation angle in degrees. |
isRevese | boolean | false | Reverses the tilt effect's rotation direction. |
springOptions | SpringOptions | Spring options for the tilt effect. |
Credits
Initiated by @AFPedreros
