Tilt

3D tilt effect that responds to mouse movement, enhancing UI elements with a dynamic depth effect, customizable rotation factors and spring options.

Examples

Basic Tilt Card

Ghost in the shell - Kôkaku kidôtai

Ghost in the Shell

Kôkaku kidôtai

Tilt with Spotlight

Example of the Spotlight component used with the Tilt component.

Ghost in the shell - Kôkaku kidôtai

2001: A Space Odyssey

Stanley Kubrick

Code

'use client';

import React, { useRef } from 'react';
import {
  motion,
  useMotionTemplate,
  useMotionValue,
  useSpring,
  useTransform,
  MotionStyle,
  SpringOptions,
} from 'motion/react';

type TiltProps = {
  children: React.ReactNode;
  className?: string;
  style?: MotionStyle;
  rotationFactor?: number;
  isRevese?: boolean;
  springOptions?: SpringOptions;
};

export function Tilt({
  children,
  className,
  style,
  rotationFactor = 15,
  isRevese = false,
  springOptions,
}: TiltProps) {
  const ref = useRef<HTMLDivElement>(null);

  const x = useMotionValue(0);
  const y = useMotionValue(0);

  const xSpring = useSpring(x, springOptions);
  const ySpring = useSpring(y, springOptions);

  const rotateX = useTransform(
    ySpring,
    [-0.5, 0.5],
    isRevese
      ? [rotationFactor, -rotationFactor]
      : [-rotationFactor, rotationFactor]
  );
  const rotateY = useTransform(
    xSpring,
    [-0.5, 0.5],
    isRevese
      ? [-rotationFactor, rotationFactor]
      : [rotationFactor, -rotationFactor]
  );

  const transform = useMotionTemplate`perspective(1000px) rotateX(${rotateX}deg) rotateY(${rotateY}deg)`;

  const handleMouseMove = (e: React.MouseEvent<HTMLDivElement>) => {
    if (!ref.current) return;

    const rect = ref.current.getBoundingClientRect();
    const width = rect.width;
    const height = rect.height;
    const mouseX = e.clientX - rect.left;
    const mouseY = e.clientY - rect.top;

    const xPos = mouseX / width - 0.5;
    const yPos = mouseY / height - 0.5;

    x.set(xPos);
    y.set(yPos);
  };

  const handleMouseLeave = () => {
    x.set(0);
    y.set(0);
  };

  return (
    <motion.div
      ref={ref}
      className={className}
      style={{
        transformStyle: 'preserve-3d',
        ...style,
        transform,
      }}
      onMouseMove={handleMouseMove}
      onMouseLeave={handleMouseLeave}
    >
      {children}
    </motion.div>
  );
}

Component API

Border Trail

PropTypeDefaultDescription
classNamestringAdditional CSS classes for styling the tilt.
styleMotionStyleAdditional CSS classes for styling the tilt.
rotationFactornumber15Controls the maximum rotation angle in degrees.
isRevesebooleanfalseReverses the tilt effect's rotation direction.
springOptionsSpringOptionsSpring options for the tilt effect.

Credits

Initiated by @AFPedreros
